BenchMark HE-X Hostile Environment Extreme Bench Scale
$0.00
The BenchMark? HE-X is a stainless steel, washdown bench scale with a removeable cover for easy cleaning in highly sanitary environments.
Download product PDF
Features
- Rugged washdown design, rigid 304 stainless steel frame and cover constructed with continuous welds
- Four adjustable stainless steel support feet
- Stainless steel IP69K load cell
- Meets Sanitary Design Principles
Specifications
Load Cell, NTEP Certified:
IP69K Stainless steel, hermetically sealed
Output Impedance:
1,000 ?
Maximum Overload:
150-200% depending on capacity
Overload Protection:
Five-point, independently adjusted
Cable Length:
10ft (3m)
Compensated Temperature Range:
14? F to 104? F (-10? C to 40? C)
Warranty:
Three-year limited warranty (includes water ingress)
Approvals:
Load cell is FM approved
Options
112044 Column,12 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to IQ+210, CW-90I, CW-90XI, 480/482 Legen Series, 680 Synergy Series
112045 Column,18 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to IQ+210, CW-90I, CW-90XI, 480/482 Legen Series, 680 Synergy Series
Models
| Part #?192346 |
Product DescriptionScale, BENCHMARK HE-X BMX1218S-50 12x18x5-1/4 50lb 10ft NTEP III SST |
|
| Part #?192347 |
Product DescriptionScale, BENCHMARK HE-X BMX1218S-100 12x18x5-1/4 100lb 10ft NTEP III SST |
|
| Part #?191455 |
Product DescriptionScale, BENCHMARK HE-X BMX1818S-50 18x18x5-1/4 50lb 10ft NTEP III SST |
|
|
Product DescriptionScale, BENCHMARK HE-X BMX1818S-100 18x18x5-1/4 100lb 10ft NTEP III SST |
|
|
Product DescriptionScale, BENCHMARK HE-X BMX1818S-150 18x18x5-1/4 150lb 10ft NTEP III SST |
|
| Part #?191458 |
Product DescriptionScale,BENCHMARK HE-X BMX1818S-200 18x18x5-1/4 200lb 10ft NTEP III SST |
|
| Part #?191459 |
Product DescriptionScale, BENCHMARK HE-X BMX1818S-250 18x18x5-1/2 250lb 10ft SST |
|
| Part #?191460 |
Product DescriptionScale, BENCHMARK HE-X BMX1818S-300 18x18x5-1/2 300lb 10ft SST |
|
| Part #?191461 |
Product DescriptionScale, BENCHMARK HE-X BMX1818S-500 18x18x5-1/2 500lb 10ft SST |
|
| Part #?191462 |
Product DescriptionScale, BENCHMARK HE-X BMX1818S-1000 18x18x5-1/2 1000lb 10ft SST |
|
|
Product DescriptionScale, BENCHMARK HE-X BMX1824S-50 18x24x5-1/4 50lb 10ft NTEP III SST |
|
| Part #?191469 |
Product DescriptionScale, BENCHMARK HE-X BMX1824S-100 18x24x5-1/4 100lb 10ft NTEP III SST |
|
| Part #?191470 |
Product DescriptionScale, BENCHMARK HE-X BMX1824S-150 18x24x5-1/4 150lb 10ft NTEP III SST |
|
| Part #?191472 |
Product DescriptionScale, BENCHMARK HE-X BMX1824S-200 18x24x5-1/4 200lb 10ft NTEP III SST |
|
| Part #?191473 |
Product DescriptionScale, BENCHMARK HE-X BMX1824S-250 18x24x5-1/2 250lb 10ft SST |
|
| Part #?191474 |
Product DescriptionScale, BENCHMARK HE-X BMX1824S-300 18x24x5-1/2 300lb 10ft SST |
|
| Part #?191475 |
Product DescriptionScale, BENCHMARK HE-X BMX1824S-500 18x24x5-1/2 500lb 10ft SST |
|
| Part #?191476 |
Product DescriptionScale, BENCHMARK HE-X BMX1824S-1000 18x24x5-1/2 1000lb 10ft SST |
|
| Part #?191479 |
Product DescriptionScale, BENCHMARK HE-X BMX2424S-100 24x24x5-1/4 100lb 10ft NTEP III SST |
|
| Part #?191480 |
Product DescriptionScale, BENCHMARK HE-X BMX2424S-150 24x24x5-1/4 150lb 10ft NTEP III SST |
|
| Part #?191481 |
Product DescriptionScale, BENCHMARK HE-X BMX2424S-200 24x24x5-1/4 200lb 10ft NTEP III SST |
|
| Part #?191482 |
Product DescriptionScale,BENCHMARK HE-X BMX2424S-250 24x24x5-1/2 250lb 10ft SST |
|
| Part #?191483 |
Product DescriptionScale, BENCHMARK HE-X BMX2424S-300 24x24x5-1/2 300lb 10ft SST |
|
| Part #?191485 |
Product DescriptionScale, BENCHMARK HE-X BMX2424S-500 24x24x5-1/2 500lb 10ft SST |
|
| Part #?191486 |
Product DescriptionScale, BENCHMARK HE-X BMX2424S-1000 24x24x5-1/2 1000lb 10ft SST |
|
