BenchPro™ BP-R Retail Digital Bench Scale

$0.00

Download product PDF
Categories: ,

Features

  • Large LCD display protected by heavy-duty tempered glass
  • Powered USB HID point of sale interface–plug and play USB interface provides power and communications
  • Interface for use with SMA, NCI and ECR
  • Battery operation for portability (BP-R 12 × 14 scale only)
  • Gravitational compensation allows for adjustment of factory calibration to meet your local gravity setting, non-approved

Specifications

Power:
Line Voltage: 100 to 240 VAC, +10% -15% (US 3-prong plug, w/ground)
Batteries (12 × 14 units only): four AA alkaline batteries (not included)

Power Consumption:
Frequency: 50/60 Hz +/-3 Hz
DC: 12 V at 0.1 amps minimum

Battery Life:
250 hrs sleep mode or 80 hrs
continuous use, backlight on 80 hrs sleep mode or 50 hrs continuous use

 Dynamic Response:
0 to 1,000 d, 1.0 sec, maximum average
1,000 d +, 1.5 sec, maximum average

Communication Ports:
RS-232 DB 9-pin male to female, straight pass through and null modem (10 ft cable included)
USB A/B type (46 in cable included)
USB HID, 2.0 full speed, vendor ID 1C19, product ID 0002

Annunciators:
Zero, gross/brutto, net, W1/W2/W3, lb, oz, kg

 Display:
Six-digit backlight LCD display with 1 in (29 mm) characters protected by heavy-duty tempered glass

Keys/Buttons:
Zero, unis, tare, F1

Temperature Range:
Certified: 14 °F to 104 °F (-10 °C to 40 °C)

Warranty:
One-year limited

Approvals:
NTEP 07-002
Measurement Canada AM-6050
CE

Options

182374 Scale, Bench Pro Series Model BP 0610-6R, 15 x 0.005lb/6 x 0.002kg, SS Weight Platter 6 in x 10 Dimensions
182375 Scale, Bench Pro Series Model BP 0610-15R, 30 x 0.01lb/15 x 0.005kg, SS Weight Platter 6 x 10 in Dimensions
182376 Scale, Bench Pro Series Model BP 1010-6R, 15 x 0.005lb/6 x 0.002kg, SS Weight Platter 10 x 10 inch Dimensions
182377 Scale, Bench Pro Series Model BP 1010-15R, 30 x 0.01lb/15 x 0.005kg, SS Weight Platter 10 x 10 inch Dimensions
179733 Scale, Bench Pro Series Model BP 1214-6R, 15 x 0.005lb/6 x 0.002kg, SS Weight Platter
179732 Scale, Bench Pro Series Model BP 1214-15R, 30 x 0.01lb/15 x 0.005kg, SS Weight Platter
