Specifications
Power – AC:
Line voltages: 115-230 VAC
Frequency: 50-60 Hz
Power Consumption:
1.5 A at 115 VAC (8 W)
0.75 A at 230 VAC (8 W)
Excitation Voltage:
+5 VDC 8 x 350? or 16 x 700? load cells
Analog Signal Input Range:
-0.5 mV/V – 4.5 mV/V
Analog Signal Sensitivity:
0.3 uV/graduation minimum, 1.5 uV/graduation recommended
A/D Sample Rate:
7.5 to 960 Hz software selectable
Resolution:
Display: 100,000 graduations maximum
System Linearity:
? 0.01% full scale
Digital I/O:
Four channels on CPU board
Circuit Protection:
RFI, EMI, ESD protection
Status Annunciators:
Designators for percent, kg, gm, lb, oz, center of zero, G/B, N, T, PT, neg, motion
Display:
Large 0.8 in 14-segment, six-digit high-intensity red LED display
Keys/Buttons:
CW-90:?Membrane keypad, 23 keys with international symbols
CW-90X:?Piezo keypad, 11 keys with international symbols
Temperature Range
Certified: 14?F to 104?F (-10?C to 40?C)
Rating/Material:
CW-90:?IP66, stainless steel
CW-90X:?IP69K, stainless steel
Warranty:
CW-90:?Two-year limited warranty
CW-90X:?Three-year limited warranty
Approvals:
CW-90:?NTEP CC 08-092,?CW-90X:?NTEP CC 08-092, Class III/IIIL 10,000d
Measurement Canada AM-5710
OIML R76/2006-GBI-10.02
EU Test Certificate GB-1385
UL/cUL Listed
CE marked
