Explorer? Precision High Capacity

$0.00

Intelligent Performance No Matter How Difficult the Task!
Download product PDF

Features

  • Applications? ? Weighing, Parts Counting, Percent Weighing, Checkweighing, Animal/Dynamic Weighing, Filling, Totalization/Statistics, Formulation, Differential Weighing, Density Determination, Peak Hold, Ingredient Costing, SQC, Statistics
  • Display? ??5.7″ (145 mm) Full-color VGA graphic touchscreen display with user-controlled brightness
  • Operation? ??AC Adapter (included) or rechargeable battery (accessory sold separately)
  • Communication? ??RS232 and USB (included) or second RS232/Ethernet (accessories sold separately) . GLP/GMP data output with real-time clock.
  • Construction? ? ?Modular design, IP54 metal base, Die-cast top housing, stainless steel pan, up-front level indicator, integral weigh below hook, calibration lock, two touchless sensors, full housing in-use cover
  • Design Features? ?Selectable environmental filters, auto tare, user selectable span calibration points, software lockout and reset menu, user selectable communication settings and data print options, user definable project and user IDs, auto standby, up to 14 operating lan

Options

Density Determination Kit. . . . . . . . . . . . . . . . . . . . 80253384
Sinker glass for Density Determination Kit . . . . 83034024
Full-featured Impact Printer SF40A . . . . . . . . . . . 30064202
SF40A Paper roll (57,5mm 2pcs) . . . . . . . . . . . . . . 12120799
SF40A Ink ribbon cassette . . . . . . . . . . . . . . . . . . . 12120798
ION-100A ? Ionizer. . . . . . . . . . . . . . . . . . . . . . . . . . . 30130302
RS232 Cable, PC 9 Pin. . . . . . . . . . . . . . . . . . . . . . . . 00410024
Cable, USB A to Mini USB, 1.8m Black. . . . . . . . . 28120263
Cable, USB-RS232 Converter . . . . . . . . . . . . . . . . . 30268619
Ethernet Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83021082
Tower Mount for Display (non High Capacity models). . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83021102
Tower Mount for Display**. . . . . . . . . . . . . . . . . . . 30078082
Display Extension Cable (9 Meter / 27 Feet). . . 30078078
Display Extension Cable (2 Meter / 6.56 Feet). . 83021083
Draftshield Kit (0.01g, 0.1g) (non High Capacity models)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83021084
Security Device (Cable & Lock). . . . . . . . . . . . . . . . 80850000
Security Device (Laptop Lock). . . . . . . . . . . . . . . . 80850043
Foot Switch Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83021086
Rolling Feet Kit**. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30041470
Rechargeable Battery Pack**. . . . . . . . . . . . . . . . . 30041295
Auxiliary Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30472064
Terminal in-use cover. . . . . . . . . . . . . . . . . . . . . . . . 83033633
Dust cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30093334

Models

  • Model #:??EX12001? ? ??Maximum Capacity? ? ?12,000 g? ? ? Readability? ? ? ?0.1 g
  • Model #:??EX24001? ? ?Maximum Capacity? ? ?24,000 g? ? ? Readability? ? ? ?0.1 g
  • Model #:??EX35001? ? ?Maximum Capacity? ? ?35,000 g? ? ? ?Readability? ? ? ?0.1 g
