Fixed/Rigid On Board Truck Weighing Kits

$0.00

For trucks with standard spring suspension, Rice Lake’s onboard scale system is created through straightforward load cell technology and an in-cab digital weight display.

Download product PDF
Categories: ,

Features

Automatic identification of any truck with any trailer for complete trailer interchangeability
Digital, two-wire weight data communications from trailer and tractor load cells for high reliability under rough environmental conditions
Self-contained trailer scale kit options
Environmentally sealed (encapsulated) radio and two0wire scale transmitter components
Plug-in system components with hardened, corrosion-proof nylon connectors
Multiple channel selection for one, two, three and four independent channel operation
Bright LED weight display over a backlit LCD message display
Any combination of half-system kits configurable for air-ride or spring-ride suspensions

Models

Part #?94532 Product DescriptionPrecision Loads On-Board Weighing System RLWS Representative Will Call You To Discuss Application And Provide Pricing
Part #?117666 Product DescriptionLoad Cell,PLSB-40K Clamp 40,000lb 2-1/8×3-3/8×16-1/4 Alloy Steel, Gauged, 4 Pin CONN, .74mV/V at 12500lbs 350 Ohms
Part #?118572 Product DescriptionSix Point Groove Lock Kit Six Point Pivot Pin Kit With Groove Lock Load Cells, In-Cab Display and Live Weigh. Labrie

Rigid Underbody Straight Truck Kit

Part #?114307 Product DescriptionKit,Four Point Underbody Coil Spring
Part #?114308 Product DescriptionKit,Six Point Underbody LC PL9710-614 Includes 14 Inch Cells And 9710 Display
Part #?114309 Product DescriptionLoad Cell Kit,RL9710-426 Four Point Heavy Duty Underbody LC Kit Includes 26in Cells and 9710 Display

Tandem Trailer Single Semi Trailer Kit

Part #?161660 Product DescriptionPLSB-40K LC Set Includes Bearing Plates Hardware and Body Springs
