Specifications
Print Method:?
Direct thermal
Resolution:
203 dpi (8 dots per mm)
Print Speed:
Up to 3.3 ips
Width:
Up to 4.1 in (10.41 cm)
Fonts:
A wide range of font types and sizes, from 6 cpi to 34 cpi depending on emulation chosen, plus scaling
International Characters:
An expanding catalog available for download. Bar Codes: 39, 128, Intlv 2 of 5, EAN08 and 13, PDF-417 and UPC, depending on emulation chosen.
Connectivity:
RS-232
Software:
Drivers and Utilities: Drivers for WIN 98, 2000, XP. compatible with Windows CE/Pocket PC and Palm OS print utilities and SDK?s.
Printer Setup program provides convenient configuration via a Windows interface from any computer
Emulations:
Emulates many popular printer brands and languages including O?Neil, Zebra CPCL and ZPL, Extech, IPL, MPL, E-Sim and Printek Mt3. Can be upgraded as new emulations become available
Ingress Protection Rating:
IP54
Print Media:
Paper Type: Direct thermal roll
Roll Size: Maximum roll diameter 2.625 in (6.7 cm) allows roll widths from 3in to 4.125 in (7.6 to 10.5 cm)
Roll Capacity: Approximately 171 ft (52.1 cm) max.
Core Size: 0.75 in (1.9 cm)
Electronics/Power:
Ruggedized screw down-type DB-9 connector for power and I/O.
DC Input: 8 to 32 VDC
Overvoltage Protection: 80 VDC for 1 hour. Failsafe to 180 VDC.
I/O Short Circuit: Tolerant of shorts to ground or DC input.
Dimensions:
(L x W x H): 7.7?x 6.6 x 3.1 in
(19.56 x 16.76 x 7.87 cm)
Weight:
2.0?lb (0.90 kg)
Memory:
2 MB Flash, 1 MB SRAM. Standard memory supports large and graphic intensive print jobs
Operating Temperature:
0? F to 185? F (-18? C to 85? C)
Operating Humidity:
10% to 90% RH (non-condensing)
Rated IP54 per IEC529
Chemical resistant case per SAEJ1455
Operator Controls And Indicators:
4 illuminated icons for general fault, wireless connection, MCR ready and battery status.
2 line LCD for system alerts and messages, configuration setup and battery charge
Buttons for power, paper feed and setup menu.
Sensors for paper out, black mark detection, and door open.
Durability And Reliability:
Survives multiple 4 foot drops to concrete (each face) and conforms to IEC 68-2
Vibration Resistance:
9.8 frms 24 to 2000 Hz
MTBF: 10,000 hours in normal use
Approvals:
FCC Class B, CE mark, UL listed AC adapters, E-mark on In-Vehicle adapters
Warranty:
One-year printer warranty on the entire printer?case and print head included
