Specifications
Power:
Input: 12 -24 VDC
Power consumption: 5W
Excitation Voltage:
5 VDC, 240 mA, 16 x 350 ?
Analog Signal Input Range:
+/- 39mV
Analog Signal Sensitivity:
0.1 ?V/graduation minimum
1.0 ?V/graduation recommended
A/D Sample Rate:
600 Hz
Resolution:
Internal resolution: 16 million counts
Weight display resolution: 999,999
System linearity: ? 0.01% full scale
Digital Inputs/Outputs:
3 inputs 5-24 VDC, 5 outputs, 115 VAC/150 mA
Serial Port:
RS-485 or RS-232 simplex supports up to 115,200 bps
Analog Output:
Optoisolated, 16 bit
0-20 mA, 4-20 mA (max 300 ohm)
0-10 VDC, 0-5 VDC (min 10,000 ohm)
Display:
Backlit graphic LCD, transmissive
128 x 64 pixel resolution, 60 x 32 mm visible area
Keyboard:
Five-key tactile keypad
Test, Zero, Tare, Print Menu, Escape, Left and Up, Navigator, Enter
Temperature & Humidity:
Working temperature: -4? F to 140? F (-20? C to 60? C)
Humidity: 85% non-condensing
Dimensions (W x H x D):
SCT converter (W x H x D): 5.82 in x 3.62 in x 2.36 in
(148 mm x 92 mm x 60 mm)
Weight:
1 lb (0.5 kg)
Rating/Material:
DIN rail mount: NEMA Type 1
Sealed enclosure: NEMA Type 4/IP67, plastic enclousre, clear cover, six PG9 cord grips
Warranty:
One-year limited warranty
