VX Series Floor Scale

$0.00

Economical Floor Scale for Basic Washdown Industrial Applications
  • VX is ruggedly constructed and includes an epoxy painted steel frame, a NEMA 4X/IP65 stainless steel indicator, NEMA 4X/IP67 sealed plastic junction box and IP67 sealed load cells.
  • The included internal rechargeable battery keeps the scale running and allows for placement of the platform away from outlets while the backlit LCD projects large 1″ digits.
  • Weighing and counting modes produces results in five weighing units, and the included RS232 provides the ability to connect the scale to a printer or PC for data reporting purposes.
Download product PDF
Category:

Features

  • Applications? Weighing, Parts Counting
  • Display? Backlit liquid crystal display (LCD), 3 color checkweighing LEDs
  • Operation? Power cord (included) or rechargeable battery (included)
  • Communication? Easy access communication port with RS232 interface (included)
  • Construction? NEMA 4X/IP65 stainless steel indicator with hinged front-cover, 5mm fixed top plate, wall bracket, epoxy painted steel platform and frame, NEMA 4/IP67 plastic junction box with side access, 4 IP67 NTEP alloy steel load cells, painted steel ramps (accessories sold separately)
  • Design Features? 125% overload protection

Options

Indicator Accessories
SF40A Statistical Impact Printer? 30064203
STP-103 Thermal Printer? 80251992
RS232 Cable? 80500552
Software, Winwedge? 80850080
Interface Kit, RS232-USB? 30304101
Interface Kit, RS232-Ethernet? 30304102
Options
Foot Kit, Set (4),? 80252545
Foot Plate, Set (2), Painted? 80252548
Bolt Kit, Floor? 80252838
Floor Stand Indicator Kit, Painted? 30047153
Floor Stand Indicator Kit, Stainless Steel? 30047154
Ramp, 48 in wide ? 48 in long, 2.5K/5K? 80252766
Ramp, 60 in wide ? 48 in long, 5K,? 80252767
Ramp, 48 in wide ? 48 in long, 10K? 80252795
Ramp, 60 in wide ? 48 in long, 10K? 80252796

Models

  • Model #:? VX32XW2500L? Maximum Capacity? 2,500 lb (1,000 kg)? Readability? 0.5 lb (0.2 kg)? Readability (Certified)? 0.5 lb (0.2 kg)
  • Model #:? VX32XW5000L? Maximum Capacity? 5,000 lb (2,200 kg)? Readability? 1 lb (0.5 kg)? Readability (Certified)? 1 lb (0.5 kg)
  • Model #:? VX32XW5000X? Maximum Capacity? 5,000 lb (2,200 kg)? Readability? 1 lb (0.5 kg)
  • Model #:? VX32XW10000L? Maximum Capacity? 10,000 lb (4,500 kg)? Readability? 2 lb (1 kg)
  • Model #:? VX32XW10000X? Maximum Capacity? 10,000 lb (4,500 kg)? Readability? 2 lb (1 kg)
